The Transplast three phase 800P series feeders are the best possible solution to guarantee absolute reliability when conveying powder products, even over large distances. The units are fitted with three phase turbines with a side channel in a design that needs no maintenance. The available powers range from 1.1 kW to 11 kW. Ask if higher powers are required.

Main features:

• Stainless steel receiver hopper.
• High efficiency side channel turbine.
• Acoustic buzzer/alarm indicating load fault
• Seal-free sealed discharge door
• Noise within the limits established by the regulations
• Receiver hopper sealed lid with four closing points
• Polyester fabric suction filter with seal in the cyclone
• Automatic filter cleaning with shaking system with pneumatic cylinder
• Design and manufacturing standard in accordance with European CE regulations
• Electric control panel with the possibility of varying the operating parameters alongside the machine with:
• Control and management module
• loading time management
• Pause time management
• Management of cleaning time and regularity

Double duo feeding installation

We can set up a double feeding system made up of a three phase turbine supplying the vacuum to two material reception hoppers. Duo system.

A small compact work station can thus be made.
